Intelligent HD Car DVR (AI Version)
Features
4G, GPS/BD, WIFI, bare disk plug and unplug, SD card, ADAS, DSM, BSD, people counting
Product Description
M51H-A1 is a highly expandable product developed for vehicle-mounted video surveillance and remote video surveillance. It is equipped with an active safety driving assistance system. It adopts a hard disk self-ejecting structure design and an embedded operating system, integrating IT cutting-edge technologies such as H.264/H.265 video compression/decompression, 3G/4G network, WIFI, GPS/BD positioning, etc. It has the characteristics of strong earthquake resistance, simple appearance, flexible and convenient installation, comprehensive functions, and high reliability. It is suitable for mobile vehicle monitoring fields such as public security police, financial escort, long-distance passenger transport, and road administration inspection.
Product Parameters
| project | Parameter Description | ||
| Audio and video input | Video Input | Optional: 4-channel AHD or 8-channel AHD input | |
| Audio Input | 4-way audio input | ||
| Audio and video output | Video Output | 1 channel optional: CVBS or VGA video output | |
| Voice Output | 1 channel voice output | ||
| Audio and Video | Video Encoding | Optional: H265, H264 encoding | |
| Parameter encoding | Video distribution rate | 1080P, 720P, D1 | |
| Audio Encoding | Optional: G726, G711A, G711U encoding | ||
| Storage Space | harddisk | 2.5-inch hard drive audio and video local storage, up to 8TB | |
| SD Card | Support 1 SD card | ||
| Wireless network | 4G Wireless | Support 1 SIM card, optional: all mainstream communication modules in the world | |
| WIFI | Optional 2.4G/5.8G | ||
| Positioning method | BeiDou IGPS | Support hybrid positioning, speed detection and time synchronization | |
| interface | USB | USB2.0 interface. Can export data. External engineering tool | |
| Serial Port | Supports 1 RS232, 1 RS485, and can be connected to external sensors | ||
| IO | Support 4-way level input, 2-way analog input, 2-way output | ||
| Network port | Support external PC. Support hybrid NVR function | ||
| Intercom | 1-way dedicated intercom hand sign | ||
| Physical specifications | size | 177(L)x186.8(W)x54(H)MM | |
| weight | 2100g | ||
| Work Environment | Operating temperature | -20~+70℃ | |
| Operating humidity | 8%-90% (no condensation) | ||
| other | Operation Mode | UI, remote control, mobile APP, WEB | |
| Gravity sensor | Built-in GSensor | ||
| Configurable AI algorithms | Driver identification, crowd counting, assisted driving, etc. | ||
