5G single-soldier portable image transmission

5G single-soldier portable image transmission

5G single-soldier portable image transmission
5G single-soldier portable image transmission - Image 2
5G single-soldier portable image transmission - Image 3
5G single-soldier portable image transmission - Image 4

Features

GPS/BD,WIFI,TF card,HDMI,4G/5G

Product Description

The 5G single-soldier portable image transmission. M71 series is a high-performance, highly expandable product developed specifically for emergency/temporary video surveillance and remote video surveillance. The product adopts an integrated design, integrating audio and video hardware encoding, 5G/4G network, GPS&Beidou, data storage, lithium battery and other modules. It can be used in combination with drones, DV cameras and other video equipment through the HDMI input interface. It is lightweight, flexible and convenient to use, comprehensive in functions and highly reliable. It is suitable for mobile monitoring fields such as electricity, law enforcement, road administration, and field photography.

Product Parameters
project Parameter Description
Audio and video input Video Input Camera with 1-way 2.5mm headphone jack
Audio Input 1 channel audio input
Audio and video output Video Output 1 channel video output
Voice Output 1- way voice output, support Bluetooth connection
Audio and video parameter encoding Video Encoding H.264 Main Profile/H.265
Video resolution 1080P , 720P, CIF optional
Audio Coding Default G.726, G.711A optional
Storage Space MicroSD card Support 1 MicroSD card (TF card)
Wireless network 5G/4G Wireless Supports 2 SIM cards

1 5G card access port, full network mode, backward compatible with 4G/3G networks

1 4G card access port, full network mode, backward compatible with 3G network
WIFI Support WiFi6, optional WiFi Client connection or WiFi AP hotspot mode
Positioning method BeiDou/GPS Support hybrid positioning, speed detection, time synchronization
power supply Battery capacity Built-in lithium battery, maximum battery life 8 hours
Power Management Key switch, automatic screen saver
Charging Mode External adapter available, suitable for Type-C interface
Screen Status screen Display geographic location, network, battery capacity, time and other status
button SOS Built-in alarm button
interface USB USB2.0/USB3.0 interface, supports data export
HDMI Support audio and video input, suitable for drones, handheld DV and other devices
power supply 1 Type-C interface
Physical specifications size 50mm (L)*100mm (W)*120mm (H) (without antenna)
weight Bare metal: 2kg
Work Environment Operating temperature -20 ～ +60℃
Operating humidity 8% ～90% (no condensation)
other Remote Control Support PC and APP connection
Scalability Provide SDK or API interface, support GB/T 28181 protocol
